Pedrollo MC 10/50

Description

The Pedrollo BC and MC series are heavy-duty submersible sewage pumps featuring a TWO-CHANNEL impeller in micro-cast AISI 304 stainless steel. The two-channel impeller design provides two large unobstructed flow passages through the impeller, allowing solids up to 50mm in diameter, short fibres, and sewage to pass freely without clogging. Cast iron body with cataphoresis treatment provides exceptional robustness and corrosion resistance for demanding permanent installation in sewage and drainage applications.

The MC 10/50 is the three-phase counterpart to the single-phase BCM 10/50, sharing the same two-channel impeller hydraulic specification while delivering the advantages of three-phase IE3 motor technology — smoother starting under load, better efficiency in continuous duty, and inverter compatibility.

The MC body (as opposed to the BC body) provides 10m submersion capability versus the BC’s 5m — making the MC 10/50 the commercial specification for deeper wet wells and sumps. 850 l/min maximum flow, 12m maximum head, two-channel AISI 304 impeller handling solids up to 50mm and short fibres.

Three-phase motor must be connected to a correctly rated motor protection switchboard — the switchboard is available on request. Cast iron body cataphoresis. IP X8. 10m cable.

• Power: 0.75 kW | Voltage: 400V Three Phase | Max Flow: 850 l/min (51 m³/h) | Max Head: 12m | Solids: up to 50mm | Motor: IE3 | Max submersion: 10m | Protection: IP X8

DISPATCH & PRICING NOTICE: The price shown (R7,780.72 incl VAT) applies to orders dispatched on Tuesdays or Thursdays. Orders dispatched on Mondays, Wednesdays or Fridays are subject to a 5% surcharge — total price R8,169.76 incl VAT. Please confirm your preferred dispatch day when placing your order.
